| SPECS | |
| Laser Power | 20W/30W |
| Engraving Area | 2.8″×2.8″/4.3″×4.3″/6.9″×6.9″/7.9″×7.9″ |
| Field Lens | F-theta 110*110mm |
| Galvo Head | SINO TECH /Focuslaser |
| Power Supply | Meanwell/ HF |
| Software | Original EZCAD2.14.11(Compatible Lightburn) |
| Gross Consumable Power | 600W |
| Operating Voltage | AC 110V/220V 50/60HZ |
| Laser Wavelength | 1064nm |
| Beam Quality | M2:1.3-1.8 |
| Repetition Precision | ±0.001mm |
| Engraving Speed | ≤9000mm/s |
| Minimum Line Width | 0.01mm |
| Character Size | 0.5-110mm |
| Cooling System | Air Cooling |
| Cable Length | 3m(5m optional) |
| Supported Files | PLT, AI, DXF, BMP, JPG, etc |
| Operating System | Win7/Win8/Win10/Win11; Mac OS |
| Service Lifespan | 100,000 hours |
Marking Materials: Gold, Silver, Stainless Steel, Copper and other materials
Features:
1) Raycus or JPT laser source
2) Less Working Space
3) Easy to use
4) Quality Assurance
Applications:
Metal Name card marking
Cans marking
Engraving medical tools
Etching on laptops and cellphones
Gift Customization
And many others.
FOCUSLASER is a leading laser company specialized in the research and develop, produce, sales, training and after-sales of laser marking/enraving/cutting machine.
